Dimension (mm) Designation Load Rating (N) Limiting Speed (rpm) Weight (kg)
d D B Open ZZ 2RS Cr Cor Grease Oil
10 30 14.3 5200 5200-ZZ 5200-2RS 7500 4300 16000 21000 0.051
12 32 15.9 5201 5201-ZZ 5201-2RS 9000 4900 14000 19000 0.053
15 35 15.9 5202 5202-ZZ 5202-2RS 10000 6000 11000 16000 0.067
42 19 5302 5302-ZZ 5302-2RS 14000 8000 10000 15000 0.124
17 40 17.5 5203 5203-ZZ 5203-2RS 12700 7800 9000 14000 0.095
47 22.2 5303 5303-ZZ 5303-2RS 17300 10400 8000 12000 0.177
20 47 20.6 5204 5204-ZZ 5204-2RS 19000 12100 8000 12000 0.160
52 22.2 5304 5304-ZZ 5304-2RS 19000 12300 8500 12000 0.221
25 52 20.6 5205 5205-ZZ 5205-2RS 20600 13900 7500 10000 0.182
62 25.4 5305 5305-ZZ 5305-2RS 27600 17800 7500 10000 0.359
30 62 23.8 5206 5206-ZZ 5206-2RS 25700 18500 6300 8500 0.296
72 30.2 5306 5306-ZZ 5306-2RS 37200 25900 6000 8000 0.558
35 72 27 5207 5207-ZZ 5207-2RS 30400 23500 5600 7500 0.454
80 34.9 5307 5307-ZZ 5307-2RS 46100 35300 5300 7000 0.667
40 80 30.2 5208 5208-ZZ 5208-2RS 40800 30200 5300 7000 0.605
90 36.5 5308 5308-ZZ 5308-2RS 54900 40100 4800 6300 0.998
45 85 30.2 5209 5209-ZZ 5209-2RS 42800 34500 4800 6300 0.640
100 39.7 5309 5309-ZZ 5309-2RS 72100 52000 4300 5600 1.360
50 90 30.2 5210 5210-ZZ 5210-2RS 43200 35300 4500 6000 0.693
110 44.4 5310 5310-ZZ 5310-2RS 84900 62600 4000 5300 1.800
55 100 33.3 5211 5211-ZZ 5211-2RS 53900 47200 4000 5300 0.969
120 49.2 5311 5311-ZZ 5311-2RS 106300 82000 3600 4800 2.360
60 110 36.5 5212 5212-ZZ 5212-2RS 61300 52600 3800 5000 1.290
130 54 5312 5312-ZZ 5312-2RS 121400 95100 3400 4500 2.920
65 120 38.1 5213 5213-ZZ 5213-2RS 73400 66600 3400 4500 1.660
140 58.7 5313 5313-ZZ 5313-2RS 137500 109600 2800 3700 3.630
70 125 39.7 5214 5214-ZZ 5214-2RS 80500 73800 3200 4300 1.800
150 63.5 5314 5314-ZZ 5314-2RS 154500 125100 2800 3800 5.030
75 130 41.3 5215 5215-ZZ 5215-2RS 87900 81400 3000 3600 1.910
160 68.3 5315 5315-ZZ 5315-2RS 171400 134800 2600 3200 6.070
